Benches

Alpine

2019

The collection features a straightforward and versatile system with a bench and a backless bench that can be combined for straight configurations, available in two lengths: 1.75 m and 2.40 m.

ECODESIGN CATALUNYA DESIGN PRIZE 2019

The concrete supports, complemented by the wooden seat and back, make it adaptable to any setting, enriching personal interaction and enabling diverse usage scenarios.
The harmonious combination of robust stone supports, and the inviting warmth of wooden planks evokes an unspecified location in the Alps, from which its name originates, imparting a feeling of well-being, tranquillity, and relaxation.

Alpine is designed for easy and intuitive on-site assembly.
The seat and backrest surfaces come pre-assembled with machined plates for screwing onto the concrete supports. Conceived to create meeting spaces, Alpine is 100% configurable in both linear compositions and standalone elements. The bench accommodates two module lengths: 1.75 m for urban settings and 2.40 m for a more landscape-oriented character.

Supports made from reinforced, etched and waterproof concrete in the Escofet standard chart colour. Optionally they are also made in recycled Eco-Grey® concrete. Seat and back formed by FSC®-certified solid pine or tropical wood with a cross-section of 135 x 50 mm. The structural elements, optional armrest and fastening elements are made from stainless steel.

It is supplied dismantled and duly protected, with assembly instructions. Each support has two ground anchoring points with stainless steel threaded sleeves recessed in the concrete. The timbers of the back and seat are fastened to the supports with tamper-proof screws.

info

Characteristics

ALPINE BANCA 240

ALPINE BANCA 240

240 x 60 x 48 cm
218 kg

ALPINE BANCA 175

ALPINE BANCA 175

175 x 60 x 48 cm
192 kg

ALPINE BANCO 175

ALPINE BANCO 175

175 x 60 x 48 (86) cm
222 kg

ALPINE BANCO 240

ALPINE BANCO 240

240 x 60 x 86 cm
250 kg

ALPINE BANCO DOBLE 175

ALPINE BANCO DOBLE 175

338 x 60 x 48 (86) cm
349 kg

ALPINE BANCO DOBLE 240

ALPINE BANCO DOBLE 240

468 x 60 x 86 cm
405 kg

ALPINE BANCA DOBLE 175

ALPINE BANCA DOBLE 175

338 x 60 x 48 cm
299 kg

ALPINE BANCA DOBLE 240

ALPINE BANCA DOBLE 240

468 x 60 x 48 cm
350 kg

ALPINE BANCA BANCO 175

ALPINE BANCA BANCO 175

338 x 60 x 48 (86) cm
330 kg

ALPINE BANCA BANCO 240

ALPINE BANCA BANCO 240

468 x 60 x 86 cm
382 kg

Installation

FIXED WITH SCREEWS

Properties

ARMREST

Certificates

Environmental Product Declaration (EPD)

FSC

Susterra

Materials and colors

Materials

ETCHED AND WATERPROOFED CONCRETE / RECYCLED CONCRETE ECO-GREY® / FSC® CERTIFICATED NORDIC PINE WOOD, HIGH-PRESSURE PROTECTED / FSC® CERTIFICATED TROPICAL WOOD, LASUR FINISHED / STAINLESS STEEL AISI 316L STRUCTURE / A2-A4 STAINLESS STEEL SCREWS

Colors

Color Gris Decapado
